Advanced React APIs: Layout Computation

🧠 Understanding useLayoutEffect: Fixing UI Flicker with Precise Layout Computation in React

When building interactive UIs, sometimes the layout of a component depends on the dimensions or position of another component. A common scenario is a tooltip that must appear either above or below a target element—based on how much space is available.

This kind of positioning logic might seem straightforward at first: just check the element’s position and update the state accordingly. But here’s where it gets tricky…

💡 The Problem: Measuring Layout After the Paint

When we render a component, the browser updates the DOM. Only after that, we can measure things like width, height, or position using methods like getBoundingClientRect().

In many cases, developers use the useEffect hook for this:

useEffect(() => {
    const rect = ref.current?.getBoundingClientRect()
    if (!rect) return
    const { height } = rect
    setTooltipHeight(height)
}, [])

This hook runs after the render is committed to the screen, so you’re measuring layout after the paint.

That means your component:

1. Renders first (possibly in the wrong position).
2. Measures its layout.
3. Updates its state.
4. Renders again (this time in the correct position).

On low-end devices, this results in visible flickering—the user briefly sees the incorrect position before the correct one is applied.

🔧 The Fix: Measuring Before the Paint with useLayoutEffect

To prevent this flickering, we can use React’s useLayoutEffect instead of useEffect. It has the exact same API, but it runs synchronously after the DOM is updated and before the browser repaints the screen.

In other words:

• useEffect → Runs after the paint.
• useLayoutEffect → Runs before the paint.

By switching to useLayoutEffect, your component can:

1. Render.
2. Measure its layout before the browser paints the screen.
3. Apply the correct positioning.
4. Show the user the correct layout immediately—no flicker!

Here’s the updated code:

useLayoutEffect(() => {
    const rect = ref.current?.getBoundingClientRect()
    if (!rect) return
    const { height } = rect
    setTooltipHeight(height)
}, [])

Now, when a user hovers over an element (like a heart icon), the tooltip will appear in the right position the first time it renders—no awkward flickering!

👩‍🔬 Real-World Example: Simulating the Flicker

In a recent test, one of our engineers added an artificial delay to simulate a low-end device scenario. On hover, the tooltip would briefly appear below the heart icon, then jump above it once layout measurements were complete.

This clearly illustrated the problem of using useEffect for layout-sensitive components. The solution? Replacing useEffect with useLayoutEffect eliminated the flicker entirely.

🧭 When to Use useLayoutEffect

You should only use useLayoutEffect when:

• You need to measure the layout of DOM elements.
• You must apply updates before the browser paints.
• You’re working with animations or precise positioning (like tooltips, popovers, modals, etc.).

For all other side effects (like fetching data, setting up subscriptions, logging, etc.), useEffect is still the preferred and more efficient choice.

📚 Further Reading

• React Docs: useLayoutEffect
• Blog: useEffect vs useLayoutEffect by Kent C. Dodds

🧠 TL;DR

• 🧩 useEffect runs after paint, leading to potential flickers.
• 🧩 useLayoutEffect runs before paint, allowing you to make layout adjustments invisibly.
• 💡 Use useLayoutEffect when layout measurements impact UI positioning on first render.

With this knowledge, your UI will look smoother, feel faster, and behave more predictably—even on low-end devices.
